|OD:||15.9~ 31.8mm||Making Method:||Cold Drawn|
carbon steel seamless tube,
carbon steel seamless pipes
Carbon Steel Tube ASTM A556 B2 C2 Superheater Steel Tube
ASTM A556 is a brief summary of the referenced standard. It is informational only and not an official part of the standard; the full text of the standard itself must be referred to for its use and application. ASTM does not give any warranty express or implied or make any representation that the contents of this abstract are accurate, complete or up to date.
1.2 The tubing sizes covered shall be 5/8 to 11/4-in. [15.9 to 31.8-mm] outside diameter, inclusive, with minimum wall thicknesses equal to or greater than 0.045 in. [1.1 mm].
1.3 Optional supplementary requirements are provided, and when desired, shall be stated in the order.
1.4 The values stated in either inch-pound units or SI units are to be regarded separately as the standard. Within the text, the SI units are shown in brackets. The values stated in each system are not exact equivalents; therefore, each system must be used independently of the other. Combining values from the two systems may result in nonconformance with the specification.
Main Grades: SA556Gr.B2, SA556Gr.C2
Chemical Requirements & Mechanical Proterties:
|Grade||C %||Si %||Mn %||P %||S %|
|B2||0.27 max||0.10 min||0.29-0.93||0.030 max||0.030 max|
|C2||0.30 max||0.10 min||0.29-1.06||0.030 max||0.030 max|
|Grade||Tensile Strength MPa||Yield Strength MPa||Hardness HRB|
|B2||410 min||260 min||79 min|
|C2||480 min||280 min||89 min|
Mark: As required.
Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.
Making Method: Cold Drawn.
Delivery status: NBK, Bright, U bending.
End: plain end, beveled end, threaded
End protection: plastic caps
Packing: Exporting package/wooden box /as requirement.
