Product Details:
|
| Materials: | CS，SS, Copper, Titanium | Diameter: | 12~120mm |
|---|---|---|---|
| Thickness: | 0.25~3mm | Bulk Weight: | 250-496kg/m3 |
| Life Span: | 3 Years | Application: | Industry,tower Packing |
| High Light: | stainless steel packing,metal raschig ring |
||
Super Metal Raschig Ring (Double metal conjugate ring)
Double metal conjugate ring is also called super metal Raschig ring, Raschig ring, the product compared with other traditional media has a load capacity of more than 33%, almost 67% for low pressure drop increase the separation efficiency of more than 12%. As a result of the energy and reduce the cost of investment. The product can be widely used as direct replacement Raschig ring packing.
Super metal Raschig ring has thin wall, heat resistance, large gap, high flux, low resistance, high separation efficiency. Especially in the vacuum distillation tower, temperature, easy decomposition, easily polymerized, carbon materials. Thus widely used in petrochemical, fertilizer, environmental protection and other industries in the packed tower.
Specification of Super Rasching Ring:
| Mechanical Data of Various Metal Super Rasching Ring | |||
| Size(mm) |
Number Per M3 |
Surface M2/M3 |
Free Volume (%) |
| 15 | 180000 | 315 | 96 |
| 20 | 145000 | 250 | 97 |
| 25 | 46500 | 180 | 98 |
| 30 | 32000 | 150 | 98 |
| 38 | 13750 | 120 | 98 |
| 50 | 9500 | 100 | 98 |
| 70 | 4300 | 80 | 98 |
Application: It is suitable for various separation, absorption and desorption devices, atmospheric and vacuum equipment, synthetic ammonia decarburization, desulfurization system, ethyl stupid separation, isooctane / clumsy separation and so on.
