Product Details:
|
| Materials: | SS, 304,304L,410,316,316L | Diameter: | 1",1.5",2",3" |
|---|---|---|---|
| Shape: | Ring | Color: | The True Color |
| MOQ: | 1 Cubic Metre | Application: | Tower Packing |
| High Light: | metal tower packing,metal raschig ring |
||
Metal pall ring packing
Supply Ability:
100 Cubic Meter/Cubic Meters per Week
Packaging Details
plastic bags or as require
Port:Shenzhen, Shanghai and any port in China
Description:
Metal Pall Ring is a kind of tower packing.,In comparison with Rasching ring,the structure is improved.the it is also widely used in the gas industry ,chemical industry ,rectifying tower and so on.
Features/function:
1)High free volume, large void space;
2)low pressure drop;
3)Top mass transfer performance
4)High floating point;high separation efficiency.
5)Excellent corrosion and heat resistance
6)Easy to install or remove. Recyclable
Application:
It's available for rectification towers, cokable systems, crude distillation unit, desulphurization system, gas liquid separator.And it is widely used in petrochemical industry, chemical industry and environmental protection, etc..
Material:
carbon steel, stainless steel304 304l 410 316 316l or Aluminum alloy, etc.
Technical data:
| Model | Size | Number per volume | Bulk density Kg/m3 | Surface area | Void volume | Packing factor M-1 |
| Dg16 | 16*16*0.4 | 214000 | 527 | 371 | 0.93 | 457 |
| Dg25 | 25*25*0.6 | 56900 | 471 | 223 | 0.94 | 268 |
| Dg38 | 38*38*0.8 | 15181 | 424 | 149 | 0.94 | 176 |
| Dg50 | 50*50*1 | 6500 | 395 | 110 | 0.95 | 128 |
| Dg76 | 76*76*1.5 | 1830 | 384 | 72 | 0.95 | 84 |
| Note: The above data is for reference only. | ||||||
