Product Details:
|
| Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Machinery | Type: | L Condenser Coil For Air Conditioner |
|---|---|---|---|
| Application: | Air Conditioner, Air Conditioner | Tube Diameter: | Up To Our Mold Sheet |
| Fin Space: | Varied Fin Space | Frame Material: | Stainless Steel, Galvanized Steel |
| Fan Brand: | Up To You | Packing: | Wooden Pallet |
| Fin Coating: | Power Painting, Epoxy, Hydrophilic | Fin Type: | Sine Wave |
| High Light: | l condenser coil finned copper tube,air conditioner finned copper tube,5mm finned copper tube |
||
Finned copper tube L condenser coil for air conditioner
Applications:
Refrigeration display cabinet
Upright Coolers
Showcase freezers
Multideck Cabinets
Island Freezers/Coolers
Impules Coolers
Ise Cream Scooping Cabints
Coffee machine
Air conditioner
Materials of Construction:
Tubes and Fins: Copper, cupro-nickel, aluminum, and stainless steel
Tube Diameters: according to our mold sheet
Casings: Aluminum, galvanized steel, and stainless steel
Optional Features:
Polycoat (Polyester) precoated aluminum fins
Baked Phenolic or Electrofin corrosion resistant coating
Bolted and gasketed removable headers
Gastight casings
Integral drainpans
Integral mist eliminators
| Tube diameter(mm) | Fin configuration(mm) | Fin surface |
| 5 | 19.05*16.5 | Window fin, Louvered fin, flat fin |
| 7 |
19.05*12.7 21*12.7 25*21.65 21*18.2 |
Window fin, Louvered fin, flat fin |
| 7.94 |
25.4*15.88 25.4*19.05 25*21.65 16*25.4 |
Window fin, Louvered fin, flat fin |
| 9.52 |
25.4*22 25*21.65 25*12.5 25*25 30*30 25.4*19.05 70*24.4 31.75*27.5 25.4*15.88 |
Window fin, Louvered fin, flat fin |
| 11.5 | 35*35 | Window fin, Louvered fin, flat fin |
| 12.2 | 20*70 | Window fin, Louvered fin, flat fin |
| 12.75 |
31.75*27.5 35*35 |
Window fin, Louvered fin, flat fin |
| 14 | 22*74 | Window fin, Louvered fin, flat fin |
| 14.5 | 45*52 | Window fin, Louvered fin, flat fin |
| 15.2 |
25*75 30*60 |
Window fin, Louvered fin, flat fin |
| 15.8 |
38.1*33 78*22.5 52*60 50*50 |
Window fin, Louvered fin, flat fin |
| 20 | 60*60 | Window fin, Louvered fin, flat fin |
| 25 | 75*65 |
Window fin, Louvered fin, flat fin |
