Product Details:
|
| Material: | 904L,317,347,347H，NO4400,NO6600 | Model Number: | BW-90 |
|---|---|---|---|
| Connection: | Welding | Type: | 45 90 180 Or As Required |
| Size: | 1/2NB - 48NB | Degree: | 30, 45, 60, 90, 180 Degree |
| Package: | Wooden Box Or Seaworthy Package | ||
| High Light: | 316l stainless steel 90 degree elbow,316l steel tubing 90 degree elbow,1/2NB stainless steel 90 degree elbow |
||
Carbon Steel Butt Welding Fittings 316L Fitting Stainless Steel 90 Deg Elbow Pipe Fitting for Pipe
Standard:GB 12459,GB/T 13401,SH 3408,SH3409,HG/T 21635,HG/T 21631,SY/T 0510,ASME B16.9,ASME B16.28
Drawing:
Nominal Pipe Size |
Center to End |
Center to Center |
Back to Back |
|||||
| 45°Elbow | 90°Elbow | 180°Return | ||||||
| DN | NPS | H | F | P | K | |||
| DN | NPS | LR |
LR |
SR |
LR |
SR |
LR |
SR |
| 15 | 1/2 | 16 | 38 | / | 76 | / | 48 | / |
| 20 | 3/4 | 19 | 38 | / | 76 | / | 51 | / |
| 25 | 1 | 22 | 38 | 25 | 76 | 51 | 56 | 41 |
| 32 | 11/4 | 25 | 48 | 32 | 95 | 64 | 70 | 52 |
| 40 | 11/2 | 29 | 57 | 38 | 114 | 76 | 83 | 62 |
| 50 | 2 | 35 | 76 | 51 | 152 | 102 | 106 | 81 |
| 65 | 21/2 | 44 | 95 | 64 | 190 | 127 | 132 | 100 |
| 80 | 3 | 51 | 114 | 76 | 229 | 152 | 159 | 121 |
| 90 | 31/2 | 57 | 133 | 89 | 267 | 178 | 184 | 140 |
| 100 | 4 | 64 | 152 | 102 | 305 | 203 | 210 | 159 |
| 125 | 5 | 79 | 190 | 127 | 381 | 254 | 262 | 197 |
| 150 | 6 | 95 | 229 | 152 | 457 | 305 | 313 | 237 |
| 200 | 8 | 127 | 305 | 203 | 610 | 406 | 414 | 313 |
| 250 | 10 | 159 | 381 | 254 | 762 | 508 | 518 | 391 |
| 300 | 12 | 190 | 457 | 305 | 914 | 610 | 619 | 497 |
| 350 | 14 | 222 | 533 | 356 | 1067 | 711 | 711 | 533 |
| 400 | 16 | 254 | 610 | 406 | 1219 | 813 | 813 | 610 |
| 450 | 18 | 286 | 686 | 457 | 1372 | 914 | 914 | 686 |
| 500 | 20 | 318 | 762 | 508 | 1524 | 1016 | 1016 | 762 |
| 550 | 22 | 343 | 838 | 559 | 1676 | 1118 | 1118 | 838 |
| 600 | 24 | 381 | 914 | 610 | 1829 | 1219 | 1219 | 914 |
| 650 | 26 | 405 | 991 | 660 | ||||
| 700 | 28 | 438 | 1067 | 711 | ||||
| 750 | 30 | 470 | 1143 | 762 | ||||
| 800 | 32 | 502 | 1219 | 813 | ||||
| 850 | 34 | 533 | 1295 | 864 | ||||
| 900 | 36 | 565 | 1372 | 914 | ||||
| 950 | 38 | 600 | 1448 | 965 | ||||
| 1000 | 40 | 632 | 1524 | 1016 | ||||
| 1050 | 42 | 660 | 1600 | 1067 | ||||
| 1100 | 44 | 695 | 1676 | 1118 | ||||
| 1150 | 46 | 727 | 1753 | 1168 | ||||
| 1200 | 48 | 759 | 1829 | 1219 |
|
|||
Our pipe fittings include unions, clamp unions, weld, clamp and threaded elbows, tees, reducers and all kinds of pipeline connecters. All products can be made according to different materials and industrial standards, such as DIN, SMS, IDF, ISO, RJT. Our products sell well in Europe, America and other countries and region
