Product Details:
|
| Material: | C12200, C11000 | Standard: | B75, B111, B280 |
|---|---|---|---|
| Application: | Gasoline, Hydraulic, And Oil Lines | Technique: | Seamless |
| OD: | 5-350mm | Wall Thickness: | 0.5-50mm Or Customised |
| Packing: | Exporting Package/wooden Box /as Requirement. | ||
| High Light: | seamless copper tube,seamless copper pipe |
||
ASTM B111 C12200 Copper Alloy Tube
C12200 copper is a lightly alloyed grade of copper, formulated for primary forming into wrought products. CW024A is the EN numeric designation for this material. C12200 is the UNS number.
Dimensions:
Outer diameter:5-350mm
Wall thickness: 0.5-50mm.
according to the buyers' requirements
Type: Copper straight tube, Copper coil/Pan cake, Copper Capillary tube
Arsenical Brass tube Symbol:
| Grade | USA | UK | Germany | Japan |
| China GB | UNS | EN | DIN | JIS H |
| T2 | C11000 | Cu-ETP | E-Cu58 | C1100 |
| TP2 | C12200 | Cu-DHP | SF-CU | C1220 |
Specification:
| Size | |
| Specifications (mm) | Wall thickness (mm) |
| 3.8 | 0.28~0.60 |
| 4.76 | 0.28~1.0 |
| 5 | 0.25~1.0 |
| 6.35 | 0.28~1.50 |
| 7~7.94 | 0.28~1.50 |
| 9~9.52 | 0.26~1.50 |
| 12~12.7 | 0.34~1.50 |
| 15.88~16 | 0.41~1.80 |
| 19.05 | 0.71~2.0 |
| 22.22 | 0.89~2.0 |
| 28.58 | 1.2~2.0 |
Application:Copper pipe and tube is widely used in Water tubes, condenser,evaporator, and heat ex-changer tubes; air conditioning and refrigeration, gas,heater, and oil burner lines; plumbing pipe and steam tubes; brewery and distillery tubes; gasoline, hydraulic, and oil lines; rotating bands etc.
Mark: As required.
