Product Details:
|
| Material: | Alumina Ceramic | Alumina Content: | 13% ~23% Or Specified |
|---|---|---|---|
| Acid Resistance (%): | >99.6 | Size: | 6mm,10mm,16mm,25mm,40mm, 50mm, 80mm Or As Required. |
| Thickness: | 0.5mm-30mm | Purity: | 95%-99.7% |
| Density: | 3.6-3.9g/cm3 | Application: | Industrial Ceramic |
| High Light: | ceramic structured packing,ceramic saddle packing |
||
High Chemical Stability Ceramic Random Packing Transfer Product For Reburner
Ceramic Cross-Partition Ring is a packing designed basically from the Raschig Ring with the cross-partitions inside to increase the surface and enhance the transfer efficiency. It is usually used extensively for the supporting packing at the bottom of tower. In general, because this packing normally has very large size, it is applied as ceramic supports for random packings.
Specification of Ceramic Cross Partition Ring:
| Specifications (mm ) | OD*ID*H*δ (mm) |
Specific surface area (m2/m3) | Void volume (m3/m3) |
Bulk number (n/m3) |
Bulk density (kg/m3) |
Dry packing (factor m-1) |
| Φ25 | 25*25*3 | 160 | 0.48 | 41000 | 660 | 582 |
| Φ50 | 50*50*5 | 145 | 0.50 | 6400 | 600 | 565 |
| Φ80 | 80**80*8 | 120 | 0.56 | 1950 | 820 | 356 |
| Φ100 | 100*100*10 | 110 | 0.53 | 1000 | 850 | 252 |
| Φ120 | 120*120*12 | 75 | 0.55 | 370 | 860 | 146 |
| Φ150 | 150*150*15 | 60 | 0.58 | 295 | 650 | 101 |
Features: excellent acid resistant properties, the ability of reisting various inorganic acid, organic acids and organic solvents corrosion(except HF acid), high temperature in a variety of occasions, c can be used at various high temperatures
Application: wide range of applications, can be used for chemical industry, metallurgy, gas and environmental protection industries in the drying tower, absorption tower, cooling tower, scrubber, regeneration tower.
