Product Details:
|
| Material: | Titanium Gr.12 | Standard: | B337,B338 |
|---|---|---|---|
| Technique: | Seamless,Welded | OD: | 3~114mm |
| Wall Thickness: | 1~6mm | Surface Treatment: | Varnish, Oil-dip, Passivation, Phosphating, Shot Blasting |
| Delivery Status: | Annealed, Normalized, Normalized+Tempered, Etc | ||
| High Light: | titanium welded tubes,small diameter titanium tubing |
||
Grades: Grade 12
Characteristics:
Ti Grade 12 is highly weldable, exhibiting improved strength allowable at increased temperatures, combined with superior crevice corrosion resistance, and excellent resistance under oxidizing to mildly reducing conditions, especially chlorides.
Chemical composition :
| Grade | Chemical composition | ||||||||||||
| 12 | O | N | C | H | Fe | AL | V | Ni | Mo | Pd | Others | Residuals | Ti |
| 0.25Max. | 0.03Max | 0.08Max | 0.015Max. | 0.30Max | 0.6-0.9 | 0.2-0.4 | 0. 4Max. | Bal | |||||
Mark: As required.
Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.
Delivery status: Annealed, normalized, normalized+Tempered, etc.
Surface treatment: oil impregnation, paint, passivation, phosphating, shot blasting etc.
Packing: Exporting package/wooden box /as requirement.
