Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material

Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material
Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material

Large Image :  Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material

Product Details:
Brand Name: Y & G
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Exporting package/wooden box / per customers’ requirement
Delivery Time: 25-35 days
Payment Terms: L/C, T/T
Supply Ability: 8000MT/Month

Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material

Description
Material: TP310H,TP310S,TP316H,TP316N,TP317… Standard: A269
Application: Boiler Heat Ex-changers OD: 7.42 - 273 Mm
Thickness: 0.5m-35mm Packing: Standard Sea-worthy Packing
High Light:

u bend pipe

,

heat exchanger u tube

Customized U Bend Tube Pickled / Bright Annealed Stainless Steel U Tube Heat Exchanger Boiler Tube



U Bending Tube

As the both ends fixed on the same tube sheet, the shell and the tube are separated so the U-type heat exchange can not thermal expanse, and the tube bundle can free stretch out and draw back, and cannot produce temperature stress due to the fluid temperature difference. The U-shaped bend is adopting hydraulic drive, bend, PLC control and pipe clamp to complete automatically. The synchronization of the cantilever and elbow movement , effectively prevents pipe sag in the bending process and adjusts speed in the process of operation. Using encoder positioning can ensure the Angle is precise, and can be set freely. In the process of running, it can not only display the movement, but also can display an error message, to help correct the operation and debug troubles, in order to ensure the safety of the operator and device and put an end to the hidden trouble of the production.



One Of Reference Drawing :



Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material 0



Testing Items:

1. Appearance Inspection;

2. Dimensional Inspection;

3. Chemical Composition Testing;

4. Mechanical Properties Testing;

5. PWHT (Solution Annealing) of U-Bend+300mm of straight length after Bending at about 680 C Holding time 5 to 7 Seconds.

6. 100% Hydrostatic test after Bending;

7. According to client’s requirement...



Application: Used in Boiler Heat Ex-changers, Fluid, Gas and Oil Transport, Pressure and Heat Transmission, Construction and Ornament, Elaborate designs available as per customers' requirements.Our U bends are suitable to return the flow of coolants/fluids at 180 degree in a much smaller space. The straight tubes are strictly implements the standard specifications and the customers' drawings requirements.



Customized U Bend Tube Pickled / Bright Annealed Stainless Steel Material 1
