OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe

OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe
OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe

Large Image :  OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe

Product Details:
Brand Name: Y&G
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiable
Packaging Details: Wooden cases, weave strips,as requirement.
Delivery Time: 25~35days
Payment Terms: L/C, T/T
Supply Ability: 8000MT per month

OD 19.05mm Nickel Alloy Tube High Creep - Rupture Strength For Rocket Motors , Inconel 718 Pipe

Description
Material: Inconel 718 / UNS N007718 Standard: ASTM B983
Type: Seamless Application: Gas Turbine Engines
OD: 6-500mm Or Customized Wall Thickness: 0.7-3mm Or Customized
Packing: Exporting Package/wooden Box /as Requirement.
High Light:

polished nickel tubing

,

polished nickel tubing

INCONEL 718 UNS N007718 / GH4169 Nickel Alloy Tube Seamless Nickel Pipe OD 19.05mm

Features: Inconel 718 is an age-hardenable nickel-chromium alloy that combines corrosion resistance with high strength and good fabricability. It has high creep-rupture strength at temperatures up to 700℃. Its excellent relaxation resistance contributes to its application in springs.


Chemical Composition:

% Ni Fe Cr Mo C Mn Si P S Co Nb+Ta Al Cu B
min 50.0 balance 17.0 2.80             4.75 0.20
max 50.0 21.0 3.30 0.08 0.35 0.35 0.015 0.015 1.00 5.50 0.80 0.30 0.006


Product Types and Standards:

Form ASTM
Rod,bar and forging B 637
Plate, sheet and strip B 670, B906
Seamless pipe and tube B 983


Physical Properties:

Density 8.23 g/cm3
Melting range 1260-1335 ℃


ApplicationsGas turbine engines, rocket motors, nuclear reactors and spacecraft.
Mark: As required.
