Product Details:
|
| Grade: | C10100, C10200, C12000, C28000,C44300, C70600, C71500... | Standard: | SB111, SB165, Etc |
|---|---|---|---|
| Wall Thickness: | 0.7-12.7mm | Outer Diameter: | 6-219.1mm |
| Application: | Heat Exchanger, Boiler, Superheater, Etc. | Package: | In Plywood Case, Steel Framed Case Or According To Clients |
| High Light: | heat exchanger tube,heat exchanger u tube |
||
C71500 copper nickel pipe U tube
Material:copper
Components: brass 66.5% ,other 33.5%
Fins or threads: n/a
Usage:heat exchanger
Grade:C71500
Size: 19.05x1.25x8000mm
Application of copper pipes
Characterisized by lighter weight, good thermal conductivity, high strength at low temperature, the copper pipes are often used in the manufacture of heat exchange equipment (such as condenser, etc.). The copper pipes are also used in the oxygen generating equipment assembly line at low temperature. Small diameter of copper tube is often used for conveying liquid pressure (such as lubrication system, hydraulic system, etc.) and is used as the instrument of piezometric tube, etc.
| Name | seamless copper (nickel) pipe |
| Standard | ASME SB165, SB111, etc. |
| Material | C10100, C10200, C12000, C28000, C12200, C44300(brass alloys), C70600(90-10), C68700(CZ110 Aluminium barss alloy), C71500(70-30), C71640(66-30-2-2),etc. |
| OD | 6-219.1mm |
| WT | 0.7-12.7mm |
| Length | 0-38000mm |
| Surface treatment | solution annealing/Light Draw/Stress Relieving Heat Treatment |
| Test requirement | 1.100% PMI / SPECTRO CHEMICAL ANALYSIS TESTS 100% PMI |
| 2.100% DIMENSION TESTS & 100% VISUAL EXAMINATION | |
| 3.TENSION TEST, FLARING TESTS(FOR SEAMLESS TUBE/PIPE)/FLANGE TESTS(FOR WELDED TUBE/PIPE), HARDNESS TEST, REVERSED FLATTENING TEST | |
| 4.100% HYDROSTATIC TEST/100% NON-DESTRUCTIVE TESTS | |
| NOTES : ALL THE TESTS AND INSPECTION NEED TO PROVIDE WITH REPORTS ACCORDING TO STANDARD AND TEST RESULTS. | |
| OPTION TEST & INSPECTION ITEMS: | |
| 1.STRAIGHTNESS TEST | |
| 2.ROUGHNESS TEST | |
| 3.CRYSTALLING PHASE ANALYSIS | |
| 4.INTERGRANULAR ATTACK TESTS | |
| 5.SHIPPING NOTIFICATION BEFORE SHIPMENT | |
| 6 .IMPACT ATTACK TEST UNDER LOW TEMPERATURE. | |
| THE DOCUMENT LSI WILL PROVIDE YOU: | |
| a. MTC (MATERIAL TEST CERTIFICATION) ACCORDING TO EN10204/3.1 OR EN10204/3.2; | |
| b.RAW MATERIAL CERTIFICATION | |
| c.ALL THE TEST & INSPECTION REPORTS AS PER PO AND STANDARDS | |
| d.HEAT TREATMENT REPORT | |
| e.SHIPPING NOTIFICATION BEFORE SHIPMENT | |
| f.QUALITY WARRANTY LETTER. | |
| Package | In bundles, plywood cases, wooden cases with water-proof package, etc. |
| Product processing | Cold drawn, cold rolled |
| Product origin | Jiangsu, China(main land). |
| Ends | PE, BE. |
| Trade terms | FOB, CIF, CFR, DDP, EXW, etc. |
| Delivery | Container, LCL, consignment. |
